Directflo 50 – 1/2″ Ported

Directflo diaphragm pumps the fluid through the center of the pump and compressed air acts on the outside face of the diaphragms.

Fluids Handled

  • Oils
  • Antifreeze
  • Windshield Wash Solution
  • DEF
  • Hydraulic Fluids
  • Diesel
  • Water
  • Waste Oil & Antifreeze

Part No.:

552 164 - DF50 Polypropylene
552 164A - DF50 Polypropylene for DEF
552 010 - DF50 Aluminum
552 030 - DF50 Aluminum
552 124 - DF50 Polypropylene Dual Inlet for Mixing

Markets Served:

Fleet service, Lube Trucks, In-Plant, Mining equipment maintenance, Car and truck dealers, Quick Lubes, Mass Transit Maintenance, Railroad

Product Specifications
1:1
14 gal/min (52 l/min)
26' (8m)
22 psi (1.5 bar)
115 psi (8 bar)
1/8" (3 mm)
3/8" NPS(F)
1/2" NPT(F)
1/2" NPT(F)
Polypropylene / PTFE / TPE / Aluminum / Stainless steel / Acetal

Directflo 100 – 1″ Ported

Directflo diaphragm pumps the fluid through the center of the pump and compressed air acts on the outside face of the diaphragms.

Fluids Handled

  • Oils
  • Antifreeze
  • Windshield Wash Solution
  • DEF

Part No.:

551 164 - DF100 Polypropylene
551 164A - DF100 Polypropylene for DEF
551 030 - DF100 Aluminum NBR Check Balls
551 010 - DF100 Aluminum Acetal Check Balls

Markets Served:

Fleet service, Lube Trucks, In-Plant, Mining equipment maintenance, Car and truck dealers, Quick Lubes, Mass Transit Maintenance, Railroad

Product Specifications
1:1
28 gal/min (106 l/min)
23' (7 m)
22 psi (1.5 bar)
115 psi (8 bar)
3/16" (4 mm)
3/8" NPS(F)
1" NPT(F)
1" NPT(F)
Polypropylene / Buna-N / Hytrel / Aluminum / Stainless steel / Acetal

Directflo 200 – 1″ Performance Series

Typical applications for polypropylene pumps are transferring and dispensing of Windshield wash and antifreeze solutions and AdBlue®/DEF.

Metal pumps have an Aluminum air motor. Typical applications for these pumps are transferring and dispensing of antifreeze solutions, lubricants, diesel, and waste oil evacuation.

Pump inlet and outlet ports can be mounted in different positions for increased installation versatility.

Fluids Handled

  • Oils
  • Antifreeze
  • Windshield Wash Solution
  • DEF
  • Diesel
  • Waste Oil & Antifreeze

Part No.:

555 030 - DP200 Aluminum Buna-N/Acetal
555 164 - DP200 Polyproylene TPE/PTFE

Markets Served:

Service Shops, Agriculture, Lube Trucks, In-Plant, Mining equipment maintenance, Car and truck dealers, Mass Transit Maintenance, Railroad

Product Specifications
1:1
53 gal/min (200 l/min)
26' (8 m)
22 (1.5 bar)
115 psi (8 bar)
1/4" (6 mm)
3/8" NSP(F)
1" ANSI B16.5 150 lb flange
1" NPT(F)
1" ANSI B16.5 150 lb flange
1" NPT(F)
Aluminum / Hytrel / Acetal / Buna-N / Polypropylene

UP20 – 2″ Ported

The UP 20 diaphragm features conventional flow design combined with unique pivoting air valve, fast action air valve for increased delivery, and reliable performance.

• Frictionless pivoting air valves
• Bolted cover design
• Long life diaphragms
• For very large volume transfer, de-watering, and fluid evacuation

Fluids Handled

  • Oils
  • Antifreeze
  • Diesel
  • Waste Oil & Antifreeze

Part No.:

554 510 - UP20 Aluminum Hytrel Check Balls

Markets Served:

Agriculture, In-Plant, Construction equipment maintenance, Mining equipment maintenance, Mass Transit Maintenance, Railroad

Product Specifications
1:1
170 gal/min (643 l/min)
26' (8 m)
22 psi (1.5 bar)
115 psi (8 bar)
1/4" (6 mm)
3/4" NPTF
2" NPTF
2" NPTF
Aluminum / Hytrel / Viton

Directflo 250 – 1 1/2″ Ported

Directflo diaphragm pumps the fluid through the center of the pump and compressed air acts on the outside face of the diaphragms.

Fluids Handled

  • Oils
  • Antifreeze
  • Windshield Wash Solution
  • DEF
  • Hydraulic Fluids
  • Diesel
  • Water
  • Waste Oil & Antifreeze

Part No.:

554 030 - DF250 Aluminum Buna-N Check Balls

Markets Served:

Fleet service, Lube Trucks, In-Plant, Mining equipment maintenance, Car and truck dealers, Quick Lubes, Mass Transit Maintenance, Railroad

Product Specifications
1:1
66 gal/min (250 l/min)
26' (8 m)
22 psi (1.5 bar)
115 psi (18 bar)
1/4" (6 mm)
1/2" NPSM(F)
1 1/2" NPT(F) & ANSI 1" B16.5 150 lb flange
1 1/2" NPT(F) & ANSI 1" B16.5 150 lb flange
Aluminum / Buna-N / Stainless Steel
